BeO AlN Al2O3 1 Watt Chip 100 Ohm 5 Watt Resistor 2.5*5mm

Product Categories
Shenzhen Yulongtong Electron Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

BeO AlN Al2O3 1 Watt Chip 100 Ohm 5 Watt Resistor 2.5*5mm

  • 1
  • 2

Brand Name : YLT

Model Number : chip

Place of Origin : China

Price : Negotiable

Payment Terms : T/T, L/C, Western Union, MoneyGram, Paypal

Delivery Time : 5-8 work days

MOQ : 100PCS

Supply Ability : 13Million PCS for RF Resistor, 7Million PCS for RF Attenuator

Packaging Details : Inside Box + Outside Carton Plus Pallet or Wooden Case if Necessary

Standard Resistance : 100Ω（4Ω-1000Ω available）

Substrate Material : BeO、 AlN 、Al2O3

Resistance Tolerance : ±5%（default）;±2%;±1%

Power Rating : 5w

Temperature Coefficient : ≤ 150ppm/℃

RoHS Compliant : RoHS Compliant

Contact Now

Chip Resistors 50Ω 100Ω 1w 5w BeO AlN Al2O3 2.5*5

FEATURES

Tab Launch
High Power
Integrated Heat Sink
Low VSWR
Easy Installation
APPLICATIONS
Mobile Networks
Broadcast
High Power Amplifiers
Isolators
Military
Instrumentation

(Product Reference)

Surface Mount Chip Resistors

额定功率 尺寸 产品型号
Power Rating Dimensions(mm) Model
(W) W L H A B 　
0.125 0.8 1.6 0.4 0.4 N/A RFR100-0.125CR8001A
0.5 1.25 2 0.4 N/A N/A RFR50A-0.5CR14301A
2 1.27 2.54 0.6 N/A N/A RFR100N-2CR2201A
2 1.5 3 0.38 1 N/A RFR50A-2CR15801A
1 1.6 3.2 1 1 N/A RFR100N-1CR45101A
5 2.5 3 1 N/A N/A RFR100-5CR0101A
5 2.5 5 1 1.25 N/A RFR100N-5CR0302A
1 2.5 5 1 1.25 N/A RFR100-1CR0302A
5 2.5 5 1 1.25 N/A RFR50-5CR0302A
8 6.35 9.5 1 N/A N/A RFR50-8CR2301A

  • (Standard Resistance):100Ω(4Ω-1000Ω available)
  • (Substrate Material):BeO, AlN,Al2O3
  • (Resistance Tolerance):± 5%(default)；± 2%；± 1%
  • (Power Rating):5～800W
  • (Temperature Range):-55～+150℃
  • (Temperature Coefficient):≤ 150ppm/℃
  • (RoHS Compliant)

(We can provide the customized product according to the customers’ requirement, such as Resistance and Configuration. )

BeO AlN Al2O3 1 Watt Chip 100 Ohm 5 Watt Resistor 2.5*5mm

BeO AlN Al2O3 1 Watt Chip 100 Ohm 5 Watt Resistor 2.5*5mm

BeO AlN Al2O3 1 Watt Chip 100 Ohm 5 Watt Resistor 2.5*5mm


Chip Resistors FAQ
Q1: When can I get the company profile, price and product information?
A4:Usually we offer you with these information within 1 hour after we get your inquiry.
Q5: How could I get a sample?
A5: If you can not buy our product in your local area, we will ship a sample to you.You will be charged a sample price plus all
related shipping costs.Express delivery charge depends on the quantity of the samples.
Q6: What is your payment terms?
A6: For first order,we need deposit,then we can start produce goods for you.
After we have good relation and know each other better, you can pay us before shipment and no need deposit.
